Features
Traffic Management
Auto Negotiation of speed and duplex modes
IEEE 802.3x Flow Control
Dynamic MAC address management
IEEE 802.1Q-based VLAN
Auto Voice VLAN
Auto Video VLAN (selected models)
VLAN routing (selected models)
QoS based on WRR, strict priority, or both
Port-based and IEEE 801.2p-based QoS
TCP/UDP-based QoS
DiffServ
IPv4 and IPv6-based QoS (selected models)
DSCP Support
Rate Limiting (ingress, or egress)
Link Aggregation and LACP
Switch Management
Insight mobile app or Insight Cloud Portal
Web browser-based management GUI
Smart Control Center Software for multi-switch management
IP Access List
IPv6 Management
Configurable Management VLAN
SNMP v1/v2c and v3
Standard MIBs (RFC1213, RFC1643, and RFC1493)
RMON group 1, 2, 3, 9
Firmware Upgrade through Smart Control Center (TFTP)
Firmware download (to switch) and upload (to server) through TFTP/HTTP
Configuration and Image Upload (to PC) through HTTP
Configuration Download (to Switch) thru TFTP/HTTP and upload (to server)
Memory & FLASH log
Syslog (server)
System password protection
NETGEAR IP Camera and WiFi Automation
Simplify the onboarding process of IP cameras and wireless access points to provide better Quality of Service (QoS) and auto-enabling multicast with the Auto-Camera and Auto-WiFi feature
Provides classification for digital camera and wireless access point packets.
Automatically places in a camera and wireless access point VLAN and then be prioritized above other packets
Room to Move
5 different ports available: 1G, 2.5G, 5G, 10G; SFP+ and cCopper
Secure Your Data
Defend with Access Control, DiffServ QoS policies, LACP Link Aggregation, Private VLANs, Denial of service protection
Cloud Management
Optional remote access for configuration, management, and monitoring through the NETGEAR Insight Cloud Portals
Specifications
Product Number
MS510TXM
Multi-gigabit copper ports
4 (1G/2.5G)
Multi-gigabit/10 Gigabit copper ports
4 (1G/2.5G/5G/10G)
SFP+ ports
2
Max MAC entries
32K
Buffer size
16Mbit
VLAN (Number Supported)
256
VLAN routing
Yes
Dynamic VLAN assignment
Yes
MLD Snooping
Yes
Static route
Yes (32)
Host ARP table
512 ARP
EEE
Yes
DoS Prevention
Yes
Internal/External PSU
Internal
Max power (worst case, all ports used, line-rate traffic)
47W
Fans
2
Acoustic Noise Level @25C
25.0 dBA
Operating Temperature
0 to 50C (32 to 122F)
MTBF
1,059,519 hrs (121 yrs)
Physical Specifications
Dimensions (W x D x H) : 330 x 206 x 43 mm ( 13.0 x 8.12 x 1.7 in)
Weight : 2.08 kg (4.25 lb)
Warranty
Limited Lifetime Hardware Warranty .
